MSA (2) Spring Cloud Gateway - Filter

FIlter



Spring Cloud Gateway에서 Filter는 요청(Request) 및 응답(Response)을 처리하거나 변환하는 데 사용된다.



필터를 설정 이유

1. 공통 로직 처리:
   • 모든 요청에 대해 동일한 작업(예: 인증, 로깅)을 중앙에서 처리가 가능하다.
2. 유연한 요청 처리:
   • 서비스별로 맞춤형 필터를 적용해 요청을 동적으로 변환이 가능하다.
3. 관리와 확장성:
   • 개별 서비스에 중복 코드를 작성할 필요 없이 Gateway에서 일괄 관리 가능하다.

---

.yml 필터 작성

server:
  port: 8000

eureka:
  client:
    register-with-eureka: true
    fetch-registry: true
    service-url:
      defaultZone: http://localhost:8761/eureka

spring:
  application:
    name: api-gateway-service
  cloud:
    gateway:
      default-filters: # 모든 요청에 공통적으로 적용
        - name: AddRequestHeader
          args:
            name: Global-Header
            value: Global-Header-Value
        - name: AddResponseHeader
          args:
            name: Global-Response
            value: Global-Response-Value

      routes:
        # 사용자 서비스 그룹
        - id: user-service
          uri: lb://USER-SERVICE
          predicates:
            - Path=/user-service/**
          filters:
            - AddRequestHeader=User-Request, User-Request-Header
            - AddResponseHeader=User-Response, User-Response-Header

        # 주문 서비스 그룹
        - id: order-service
          uri: lb://ORDER-SERVICE
          predicates:
            - Path=/order-service/**
          filters:
            - name: RewritePath
              args:
                regexp: "/order-service/(?<segment>.*)"
                replacement: "/${segment}"
            - name: Hystrix
              args:
                name: orderFallback
                fallbackUri: forward:/fallback/order-service

        # 결제 서비스 그룹
        - id: payment-service
          uri: lb://PAYMENT-SERVICE
          predicates:
            - Path=/payment-service/**
          filters:
            - name: RequestRateLimiter
              args:
                redis-rate-limiter.replenishRate: 10
                redis-rate-limiter.burstCapacity: 20



코드 레벨 필터 구현

@Configuration
public class FilterConfig {

    @Bean
    public RouteLocator gatewayRoutes(RouteLocatorBuilder builder) {
        return builder.routes()
                // 사용자 서비스
                .route("user-service", r -> r.path("/user-service/**")
                        .filters(f -> f.addRequestHeader("User-Request", "User-Request-Header")
                                .addResponseHeader("User-Response", "User-Response-Header"))
                        .uri("lb://USER-SERVICE"))

                // 주문 서비스
                .route("order-service", r -> r.path("/order-service/**")
                        .filters(f -> f.rewritePath("/order-service/(?<segment>.*)", "/${segment}")
                                .hystrix(config -> config.setName("orderFallback")
                                        .setFallbackUri("forward:/fallback/order-service")))
                        .uri("lb://ORDER-SERVICE"))

                // 결제 서비스
                .route("payment-service", r -> r.path("/payment-service/**")
                        .filters(f -> f.requestRateLimiter(config -> config.setRateLimiter(redisRateLimiter())))
                        .uri("lb://PAYMENT-SERVICE"))
                .build();
    }

    // Redis 기반 Rate Limiter Bean 등록
    private RedisRateLimiter redisRateLimiter() {
        return new RedisRateLimiter(10, 20);
    }
}



Custom Filter 구현

@Component
@Slf4j
public class CustomFilter extends AbstractGatewayFilterFactory<CustomFilter.Config> {

    public CustomFilter() {
        super(Config.class);
    }

    @Override
    public GatewayFilter apply(Config config) {
        return ((exchange, chain) -> {
            // Pre Filter
            ServerHttpRequest request = exchange.getRequest();
            long startTime = System.currentTimeMillis();
            log.info("Custom Pre Filter: Request ID -> {}", request.getId());
            log.info("Custom Pre Filter: URI -> {}", request.getURI());

            // Add a custom request header
            ServerHttpRequest modifiedRequest = request.mutate()
                    .header("Custom-Request-Header", "CustomRequestValue")
                    .build();

            // Post Filter
            return chain.filter(exchange.mutate().request(modifiedRequest).build())
                    .then(Mono.fromRunnable(() -> {
                        ServerHttpResponse response = exchange.getResponse();
                        long processingTime = System.currentTimeMillis() - startTime;

                        log.info("Custom Post Filter: Response Status Code -> {}", response.getStatusCode());
                        log.info("Custom Post Filter: Processing Time -> {}ms", processingTime);

                        // Add a custom response header
                        response.getHeaders().add("Custom-Response-Header", "CustomResponseValue");
                    }));
        });
    }

    public static class Config {}
}

server:
  port: 8000

eureka:
  client:
    register-with-eureka: false
    fetch-registry: false
    service-url:
      defaultZone: http://localhost:8761/eureka

spring:
  application:
    name: api-gateway-service
  cloud:
    gateway:
      routes:
        # 첫 번째 서비스
        - id: first-service
          uri: http://localhost:8081/
          predicates:
            - Path=/first-service/**
          filters:
            - CustomFilter

        # 두 번째 서비스
        - id: second-service
          uri: http://localhost:8082/
          predicates:
            - Path=/second-service/**
          filters:
            - CustomFilter

      default-filters:
        - name: AddRequestHeader
          args:
            name: Global-Request
            value: GlobalRequestValue
        - name: AddResponseHeader
          args:
            name: Global-Response
            value: GlobalResponseValue
